Hikvision DS-7108HGHI-M1/T 08 Channel Mini 1U DVR

Share:

Hikvision DS-7108HGHI-M1/T 08 Channel Mini 1U DVR

Hikvision DS-7108HGHI-M1/T 08 Channel Mini 1U DVR

Model: DS-7108HGHI-M1/T

Reviews: No reviews yet

Price: 3,200.00৳

Regular Price: 3,850.00৳

Save: 650.00৳

Key Features:

  • Analog Video Input: 8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
  • HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
  • Synchronous playback: 8-ch
  • Video Bitrate: 32 Kbps to 4 Mbps
  • Total Bandwidth: 72 Mbps
  • SATA: 1 SATA interface
  • Video Output Mode: HDMI/VGA simultaneous output
  • IP Camera Input: 2-ch (up to 10-ch) Up to 5MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
  • Audio Output: 1-ch, RCA (Linear, 1 KΩ)
  • Stream Type: Video, Video & Audio
  • Capacity: Up to 4 TB capacity for each disk
Buy Now

Specifications

Audio and Video

Analog Video Input 8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input 1080p25, 1080p30, 720p25, 720p30
AHD Input 1080p25, 1080p30, 720p25, 720p30
HDCVI Input 1080p25, 1080p30, 720p25, 720p30
CVBS Input Support
HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Two-Way Audio Reuse the first audio input
Synchronous playback 8-ch
Video Output Mode HDMI/VGA simultaneous output
IP Camera Input 2-ch (up to 10-ch) Up to 5MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras

Recording

Encoding Resolution For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p stream access: 720p/WD1/4CIF/VGA/CIF For SD stream access: WD1/4CIF/VGA/CIF
Video Bitrate 32 Kbps to 4 Mbps
Audio Bitrate 64 Kbps

Network

Remote Connection 64
Total Bandwidth 72 Mbps
Network Protocol TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™, HTTPS
Network Interface 1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface

SATA 1 SATA interface
USB Interface Rear panel: 2 × USB 2.0
Alarm In/Out N/A

Power Type

Power Supply 12 VDC, 1.5 A
Power Consumption ≤ 10 W (without HDD)

Environmental

Working Temperature -10 °C to 55 °C (14 °F to +131 °F)
Working Humidity 10% to 90%

Physical Specification

Dimension 200 × 200 × 48 mm (7.9 × 7.9 × 1.9 inch)

Audio Sound & Microphone

Audio Input 1-ch RCA (2.0 Vp-p, 1 KΩ) 8-ch via coaxial cable
Audio Output 1-ch, RCA (Linear, 1 KΩ)

Compression Standard

Video Compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Audio Compression G.711u

Video

Frame Rate Main stream: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream: For 1080p and 720p stream access CIF/QVGA@15 fps For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)
Stream Type Video, Video & Audio

Capacity

Capacity Up to 4 TB capacity for each disk

Description

Hikvision DS-7108HGHI-M1/T 08 Channel Mini 1U DVR

The Hikvision DS-7108HGHI-M1/T is a compact, 8-channel Mini 1U Digital Video Recorder (DVR) designed for small to medium-scale surveillance systems requiring reliable, high-definition video recording and monitoring. Ideal for homes, retail stores, offices, and small businesses, this DVR supports hybrid operation, allowing you to connect a mix of analog, AHD, CVI, and TVI cameras—providing flexibility for both new installations and system upgrades.
With support for up to 5MP resolution on all channels, the DS-7108HGHI-M1/T delivers crisp, clear video footage for accurate identification and monitoring. It features H.265+ intelligent video compression technology, which significantly reduces bandwidth and storage consumption without compromising image quality, enabling longer recording times and more efficient data management.
The DVR comes equipped with a built-in HDMI output for high-resolution local viewing and supports simultaneous HDMI and VGA dual-output, allowing flexible display options. It also includes 1 SATA interface for up to 6TB of storage (expandable with external drives via USB), ensuring ample space for extended video retention.
User-friendly features include 4-in-1 connectivity (AHD/CVI/TVI/CVBS), smart search functions, and motion detection with customizable zones. Remote access is seamless via the Hik-Connect app or Hikvision’s web client, enabling real-time monitoring and playback from smartphones, tablets, or PCs. Two-way audio support via BNC and RCA ports adds enhanced communication capabilities.
Designed for ease of installation and operation, the DS-7108HGHI-M1/T features plug-and-play functionality with auto-detection of connected cameras. Its compact 1U form factor saves space, making it perfect for environments with limited rack or desk room.
Powered by Hikvision's top-notch reliability and advanced security capabilities, the DS-7108HGHI-M1/T delivers a budget-friendly, adaptable, and forward-thinking surveillance solution to meet today's monitoring demands.
