TP-Link VIGI NVR1004H-4P 4 Channel PoE+ NVR

TP-Link VIGI NVR1004H-4P 4 Channel PoE+ NVR

Model: VIGI NVR1004H-4P

Reviews: No reviews yet

Price: 7,400.00৳

Regular Price: 9,670.00৳

Save: 2,270.00৳

Key Features:

  • Brand: TP-Link
  • IP Video Input: 4-Channel
  • Incoming Bandwidth: 80 Mbps
  • Outgoing Bandwidth: 60 Mbps
  • Mobile Phone Access: Android, iOS
  • Interoperability: ONVIF, CGI
  • USB Interface: 2× USB 2.0
  • SATA: 1 SATA Interface
  • Warranty Details: 1 Year
Buy Now

Specifications

General Information

Brand TP-Link
Model VIGI NVR1004H-4P
Type Network Video Recorder

Audio and Video

IP Video Input 4-Channel
Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 60 Mbps
HDMI Output Resolution 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
VGA Output Resolution 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video Output Mode HDMI/VGA Simultaneous Output
Multi-View Display 1/4

Decoding

Audio Compression G.711A/G.711U/G.726
Decoding Format H.265+/H.265/ H.264+/H.264
Video Compression H.265+/H.265/ H.264+/H.264
Record Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Live View/Playback Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/ DCIF/2CIF/CIF/QCIF
Synchronous Playback 4 Channel
Decoding Capability 2-ch @ 8MP, 4-ch @ 4MP

Recording Administration

Record Mode • Manual Recording
• Scheduling Recording
• Motion Detection Recording
Playback Mode • Instant Playback
• Regular Playback
• Tag Playback
• Event Playback
Backup Mode • Regular Backup
• Video Clip Backup
Playback Function • Play
• Pause
• Stop
• Fast Forward
• Fast Backward
• Play By Frame
• Full Screen
• Video Clip
• Export Clip
• Digital Zoom
• Lock Recording
• Audio On/Off

Network

Protocol TCP/IP, DHCP, DNS, NTP, UPnP
Mobile Phone Access Android, iOS
Incoming Bandwith 80 Mbps
Outgoing Bandwidth 60 Mbps
Web Browser Chrome (57+), Firefox (52+), Edge (91+)
Interoperability ONVIF, CGI

External Interface

Network Interface 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
USB Interface 2× USB 2.0
Audio Interface 1-ch RCA Input; 1-ch RCA Output
Alarm In/Out N/A
Serial Interface N/A
Power 1× DC Jack
Reset Button 1
Speaker N/A
eSATA N/A
HDMI 1
VGA 1

HARD DISK

SATA 1 SATA Interface
Capacity Up to 16 TB

PoE

Standard 802.3at/af Compliant
Interface 1- 4, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
PoE Budget 53 W△ Available for All PoE+ Ports, 30 W Max per Port
PoE Standard: 802.3af/at
PoE Ports: Ports 1-4
PoE Budget: 53 W

Alarm

General Alarm • Motion Detection
• Video Tampering
• Scene Change Detection
• Line-Crossing Detection
• Intrusion Detection
• Region Entering Detection
• Region Exiting Detection
• Loitering Detection
• Object Abandoned/Removal Detection
• Vehicle Detection
• Human Detection
• Abnormal Sound Detection
• Smart Frame
Anomaly Alarm • Video Loss
• Offline and IP Conflict
• Disk Exception
• Login Exception
Alarm Linkage • Recording
• White Light Alarm
• Buzzer
• Log
• Audible Alarm

Environmental

Operating Temperature -10–55 °C
Storage Temperature -40–70 °C
Storing/Storage Humidity 10%~90% RH Non-Condensing
Working Temperature • NVR: -10–55 °C
• Power Adapter: 0–40 °C
Working Humidity 10%~90% RH Non-Condensing

Power Type

External Power Supply 53.5V DC/1.31A
Power Supply 53.5V DC/1.31A
Max. Power Consumption 4.25 W (without disk)

Certification

Certifications CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI

VIDEO/IMAGE

Video Input 4-Channel IP Video Input, up to 8MP Resolution
Recording Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/ DCIF/2CIF/CIF/QCIF
HDMI Output Resolution 1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz
VGA Output Resolution 1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz

Physical Specification

Package Content VIGI Network Video Recorder
Power Adapter
HDD Screws
Mouse
Quick Installation Guide

Warranty Information

Warranty Details 1 Year

Description

TP-Link VIGI NVR1004H-4P 4-Channel PoE NVR – All-in-One Surveillance result for Small to Medium Businesses

Insure smart, secure, and flawless videotape monitoring with the TP-Link VIGI NVR1004H-4P, a compact yet important 4-channel PoE Network Video Archivist designed for small to medium-sized surveillance systems. Ideal for retail stores, services, homes, and small storages, this NVR offers easy setup, high-description recording, PoE power force, and intelligent features to cover what matters most.

All-in-One 4-Channel Video Surveillance Hub

The VIGI NVR1004H-4P supports up to 4 high-resolution IP cameras, making it a perfect fit for businesses or locales taking modest but dependable videotape surveillance content. With real-time recording and monitoring, this NVR ensures that every critical moment is captured easily and efficiently.

Whether you’re watching over your entry points, lobby, storehouse area, or out-of-door demesne, this NVR gives you full control and oversight from a single, intuitive platform.

Integrated PoE for Easy Camera Deployment

Forget about complicated installations. The VIGI NVR1004H-4P features 4 erected-in PoE(Power over Ethernet Plus) anchorages, allowing you to connect and power compatible VIGI cameras with a single Ethernet string. This significantly simplifies setup and reduces costs by barring the need for separate power sources or redundant wiring.

Each PoE harborage can supply up to 30W of power, icing comity with high-performance surveillance cameras that bear further energy for advanced features like infrared night vision and motorized drone.

High-Definition Recording with Effective Compression

Capture and store videotape footage in over to 5MP resolution, delivering sharp images for accurate identification and detail analysis. Whether you are reviewing daytime events or night intrusions, the VIGI NVR1004H-4P ensures high clarity in every frame.

The advanced H.265 videotape contraction format enables effective bandwidth operation and reduces storehouse demands without immolating videotape quality. This allows you to record longer and store more data using lower fragment space, making your surveillance system more cost-effective.

Flexible storehouse and Playback Options

The NVR1004H-4P supports a single SATA hard drive over to 10 TB, giving druggies plenitude of space to store weeks or indeed months of surveillance footage. Smart recording modes including listed, stir-touched off, and nonstop recording give flexible options to meet your specific security requirements.

Smart playback lets druggies snappily search footage by time, stir events, or custom labels, allowing for fast and effective videotape review. Export important clips fluently for legal or reporting purposes.

Remote Viewing Anytime, Anywhere

Stay connected to your surveillance system from nearly anywhere using the VIGI Security App or VIGI Security Management System(VIGI CMS). Ever view live footage, playback recordings, and admit real-time cautions directly on your smartphone or PC.

The NVR also supports web access via a cybersurfer, so you can securely cover and manage your cameras from any internet-connected device. SSL encryption and secure stoner authentication keep your surveillance data safe from unauthorized access.

Smart Discovery Features for Proactive Security

Integrating impeccably with VIGI cameras, the NVR1004H-4P enables intelligent discovery features similar as stir discovery, line crossing, intrusion discovery, and tampering cautions. These smart features help minimize false admonitions and enhance situational mindfulness, icing quick response in case of suspicious exertion.

Admit drive announcements or dispatch cautions the moment abnormal exertion is detected, allowing you to act before incidents escalate.

Compact, Reliable, and stoner-Friendly

With a compact and fanless design, the TP-Link VIGI NVR1004H-4P operates quietly and efficiently, making it ideal for quiet surroundings similar as homes, services, or event areas. It also offers HDMI and VGA videotape affair, allowing for real-time original monitoring with easy display connectivity.

Setup is quick and hassle-free, thanks to the intuitive stoner interface and bus camera discovery point. Indeed druggies with limited specialized knowledge can emplace a dependable and secure surveillance system in twinkles.

Crucial Features at a regard

 Supports 4 IP cameras

 Erected-in 4x PoE anchorages for easy draw-and-play camera installation

 Up to 5MP resolution for demitasse-clear videotape

 Contraction reduces bandwidth and storehouse needs

 Supports 1 SATA HDD up to 10 TB

 Remote monitoring via VIGI App, CMS, and web cybersurfer

 Intelligent discovery stir, line crossing, intrusion, camera tampering

 HDMI and VGA affair for original live view

 Compact and silent fanless design for inner surroundings

The TP-Link VIGI NVR1004H-4P is your ideal entry-point into professional-grade surveillance. With erected-in PoE, smart discovery, remote access, and high-resolution recording, it combines performance and convenience in one satiny, important unit — backed by TP-Link’s trusted trustability.
