MSI PRO B650M-E AM5 mATX AMD Motherboard
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4 Thumbnail 5

MSI PRO B650M-E AM5 mATX AMD Motherboard

☆ ☆ ☆ ☆ ☆
(0 Reviews) | In Stock | Brand: Msi
৳11,650 ৳12,800 Save 9%

Key Features

  • Chipset: AMD B650
  • Memory Type: DDR5
  • Form Factor: mATX<br> 211mmx243.84mm
  • Audio: 1x Front Audio (JAUD)
  • Maximum Memory: 128GB
  • HDMI: 1x HDMI 2.1
Physical Specification
Form Factor mATX<br> 211mmx243.84mm
Sockets 1x M.2<br> M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G
Bios Information
BIOS Type Flash BIOS Button
Audio Sound & Microphone
Audio 1x Front Audio (JAUD)
Ports & Slots
PCI-E 1x PCI-E x16 slot Supports x16 (For Ryzen 9000/ 7000 Series processors)<br> Supports x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors)<br> Supports x4 (For Ryzen™ 8500/ 8300 Series processors)<br> 1x PCI-E x1 slot<br> PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)<br> PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
Slots 2 x UDIMM
HDMI 1x HDMI 2.1
VGA 1x VGA
USB 2x USB 2.0 (Rear)<br> 4x USB 2.0 (Front)<br> 4x USB 5Gbps Type A (Rear)<br> 2x USB 5Gbps Type A (Front)
RJ45 (LAN Port) Realtek RTL8111H Gigabit LAN
Internal I/O Ports 1x Power Connector(ATX_PWR)<br> 1x Power Connector(CPU_PWR)<br> 1x CPU Fan<br> 2x System Fan<br> 2x Front Panel (JFP)<br> 1x Chassis Intrusion (JCI)<br> 1x Front Audio (JAUD)<br> 1x Com Port (JCOM)<br> 1x RGB LED connector(JRGB)<br> 1x TPM pin header(Support TPM 2.0)<br> 4x USB 2.0 ports<br> 2x USB 5Gbps Type A ports
Memory
Supported Memory Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ <br>6000(OC)/ 5800(OC)/ <br>5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz<br> Max. overclocking frequency:<br> 1DPC 1R Max speed up to 6800+ MHz<br> 1DPC 2R Max speed up to 6000+ MHz<br> Supports Dual-Channel mode<br> Supports non-ECC, un-buffered memory<br> Supports AMD EXPO
Maximum Memory 128GB
Memory Type DDR5
General Information
Storage Temperature 1x M.2<br> M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices<br> 4x SATA 6G
RAID
RAID Type Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Security
TPM 1x TPM pin header(Support TPM 2.0)
Warranty Information
Warranty 3 Years Warranty
CPU
Chipset AMD B650
Supported CPU Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Graphics
Graphics 1x HDMI<br> Support HDMI 2.1, maximum resolution of 4K 60Hz 1x DisplayPort<br> Support DisplayPort 1.4, maximum resolution of 4K 60Hz

MSI PRO B650M-E AM5 mATX AMD Motherboard

The MSI PRO B650M‑E is a solid micro‑ATX motherboard built for the AMD AM5 platform, offering a compact yet powerful foundation for modern Ryzen builds. Designed to accommodate the latest Ryzen 7000 and beyond, it supports full compatibility with AM5 CPUs, allowing for future upgrades without changing your motherboard.
Memory capabilities are strong: the board features two DDR5 DIMM slots that support high‑speed, dual‑channel configurations. This lets users install up to 128 GB of RAM, delivering excellent performance for gaming, content creation, or multitasking. The board’s power design ensures stable and efficient voltage delivery to the CPU, even under demanding workloads, thanks to its carefully engineered VRM layout and cooling.
For expansion, the PRO B650M‑E includes a PCIe 4.0 x16 slot for a graphics card and an additional PCIe x1 slot for peripheral cards. Storage options are versatile, with a PCI‑Express Gen‑4 M.2 slot for ultra-fast NVMe SSDs and several SATA ports for traditional HDDs or SATA-based SSDs, giving you flexibility in building your storage setup.
Networking is handled by a reliable gigabit Ethernet port, offering stable wired connectivity for gaming or productivity. On the rear I/O, you’ll find a range of USB ports—including modern USB‑C or USB‑A depending on revision—and legacy USB 2.0 support for older peripherals. Video output is available via HDMI for processors with integrated graphics.
The board also offers practical features like an EZ Debug LED system for troubleshooting, and a BIOS Flash Button, which allows you to update the BIOS even without a CPU installed. Cooling is well covered: a compact heatsink helps regulate voltage-regulator temperatures, promoting consistency in long sessions.
With its robust build quality, versatile connectivity, and forward‑looking AM5 support, the MSI PRO B650M‑E is a dependable choice for users building a powerful yet space-efficient AMD system
