PCI Slot
2x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
Slots
4
Display Port
2x DisplayPort 1.4
USB
2x USB 2.0 (Rear)<br>
4x USB 2.0 (Front)<br>
2x USB 3.2 Gen1 Type A (Rear)<br>
4x USB 3.2 Gen1 Type A (Front)<br>
1x USB 3.2 Gen1 Type C (Front)<br>
2x USB 3.2 Gen2 Type A (Rear)
RJ45 (LAN Port)
Realtek RTL8125BG 2.5G LAN
Internal I/O Ports
x Power Connector(ATX_PWR)<br>
2x Power Connector(CPU_PWR)<br>
1x CPU Fan<br>
1x Pump Fan<br>
2x System Fan<br>
2x Front Panel (JFP)<br>
1x Chassis Intrusion (JCI)<br>
1x Front Audio (JAUD)<br>
1x Com Port (JCOM)<br>
2x Addressable V2 RGB LED <br>connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)<br>
4x USB 2.0 ports<br>
4x USB 3.2 Gen1 Type A ports<br>
1x USB 3.2 Gen1 Type C ports
