Hikvision DS-7104NI-Q1/M 4 Channel Mini 1U NVR

Hikvision DS-7104NI-Q1/M 4 Channel Mini 1U NVR

☆ ☆ ☆ ☆ ☆
(0 Reviews) | In Stock | Brand: Hikvision
৳4,480 ৳4,850 Save 8%

Key Features

  • IP Video Input: 4-ch Up to 6 MP resolution
  • Incoming Bandwidth: 40 Mbps
  • Outgoing Bandwidth: 60 Mbps
  • Video Output Mode: HDMI/VGA simultaneous output
  • Decoding Format: H.265+/H.265/ H.264+/H.264
  • Synchronous Playback: 4-ch
Audio and Video
IP Video Input 4-ch Up to 6 MP resolution
Incoming Bandwidth 40 Mbps
Outgoing Bandwidth 60 Mbps
Video Output Mode HDMI/VGA simultaneous output
HDMI Output 1-ch, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output 1-ch, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Decoding
Decoding Format H.265+/H.265/ H.264+/H.264
Recording Resolution 6 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous Playback 4-ch
Decoding Capability 4-ch@1080p (30 fps) or 2-ch@4 MP (30 fps) or 1-ch@6 MP (30 fps)
Stream Type Stream Type
Network
Network Interface 1, RJ-45 10/100Mbps self-adaptive Ethernet interface
Remote Connection 16
Auxiliary Interface
SATA 1 SATA interface
Alarm In/Out N/A
USB Interface Rear panel: 2 × USB 2.0
Power Type
Power Supply 12 VDC, 1.5 A
Power Consumption ≤ 10 W
Environmental
Working Temperature Working Temperature
Working Humidity 10% to 90%
Physical Specification
Dimension 265 × 223 × 48 mm (10.4" × 8.8" × 1.9")
Networking & Connectivity
Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™
Capacity
Capacity Up to 6TB capacity for each disk
Warranty Information
Warranty 01 Year Warranty

Hikvision DS-7104NI-Q1/M 4 Channel Mini 1U NVR

The Hikvision DS-7104NI-Q1/M is a compact 1U network video recorder (NVR) that supports up to 4 IP cameras, making it ideal for small-scale surveillance deployments in homes, small businesses, or branch offices. Despite its small chassis, it offers efficient performance and smart features in a space-saving design.
This NVR uses advanced video compression technologies — including H.265+, H.265, H.264+, and H.264 — to significantly reduce bandwidth and storage demands without compromising video quality. Incoming network bandwidth is capped at 40 Mbps, while outgoing reaches 60 Mbps, ensuring stable throughput for multi-channel recording and remote streaming.
It supports up to 4 camera inputs with resolutions up to 6 MP, and decodes up to four 1080p channels simultaneously for live viewing and playback.
For output, it provides both HDMI and VGA ports, allowing you to view live feeds or recorded footage on a variety of monitors.
In terms of storage, the device has one SATA port, supporting hard drives up to 6 TB.
There are also two USB 2.0 ports for exporting recordings, backing up data, or connecting peripherals.
Smart functionality includes line-crossing and intrusion detection, and a smart-search feature lets you find motion or events in specific areas within recorded video.
The NVR supports up to 16 remote connections, enabling multiple users to view or manage the system via Hik-Connect or other network tools.
It runs on a low-power 12 V DC / 1.5 A supply, consuming less than 10 W, which makes it efficient and cost-effective.
Designed to operate reliably in various environments, it tolerates temperatures from –10 °C to +55 °C.
Overall, the Hikvision DS-7104NI-Q1/M offers a balanced mix of compact form, efficient encoding, smart analytics, and reliable remote access — ideal for users who need a capable yet space-efficient NVR for a 4-camera setup.
