DeepCool PL550D 550 Watt Non-Modular 80 Plus Bronze ATX 3.0 Power Supply

DeepCool PL550D 550 Watt Non-Modular 80 Plus Bronze ATX 3.0 Power Supply

Model: PL550D

Reviews: No reviews yet

Price: 5,950.00৳

Regular Price: 6,580.00৳

Save: 630.00৳

Key Features:

  • Product Type: ATX12V V3.0
  • Maximum Power: 550 Watt
  • Color: Black
  • Form Factor: ATX
  • Manufacturing Warranty: 5 Years

Specifications

Basic Information

Product Type ATX12V V3.0
PSU Category Non Modular

Fan / Cooling System

Fan Size 120mm
Fan Bearing HYB(Hydro Bearing)

Performance

Efficiency 85% Efficiency
Efficiency Rating 80 Plus Bronze
PFC (Power Factor Correction) 100-150ms
Hold Up Time >=16ms

Protection

Protection OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Over Voltage Protection (OVP) Yes
Over Power Protection (OPP) Yes
Over Current Protection (OCP) Yes
Over Temperature Protection (OTP) Yes
Short Circuit Protection (SCP) Yes
Under Voltage Protection (UVP) Yes

Ports & Slots

ATX Main Connectors 1
EPS Connectors 2
PCIe Connectors 3
SATA Power Connectors 4

Power Type

Maximum Power 550 Watt
Input AC 100 - 240Vac, 8 - 4A, 50 - 60Hz
Input Voltage 100 - 240Vac100 - 240Vac
Input Frequency Range 50 - 60Hz
Input Current 8 - 4A

Environmental

Operating Temperature 0 - 40 Degree C

Physical Specification

Color Black
Form Factor ATX
Dimension 150 x 140 x 86mm

Technical Info

MTBF 100,000 Hours

Additional Info / Features

Regulatory / Safety Approval CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH

Warranty Information

Manufacturing Warranty 5 Years

Description

The DeepCool PL550D 550 Watt Non-Modular 80 PLUS Bronze ATX 3.0 Power Supply is a robust and efficient power supply unit designed to meet the demands of modern computer systems. With its 80 PLUS Bronze certification, it ensures energy efficiency with up to 85% efficiency under typical loads, reducing power wastage and heat generation. Equipped with a 120mm hydro-bearing fan, the DeepCool PL550D functions silently while delivering superior cooling performance. It is a non-modular unit, meaning all the cables are attached, making it ideal for systems where cable management is not a primary concern1. The power supply is equipped with multiple connectors, including a 20+4 Pin Main Power Connector, a 4+4 Pin CPU Connector, and 6+2 Pin PCI-E Connectors, ensuring compatibility with a wide range of components. The DeepCool PL550D is built to last, backed by a 5-year warranty. It also includes comprehensive protection mechanisms, such as Over Voltage Protection (OVP), Over Current Protection (OCP), Short Circuit Protection (SCP), Over Power Protection (OPP), No Load Operation Protection (NLO), Over Temperature Protection (OTP) is a crucial safety feature that guards your system against electrical irregularities by shutting down the power supply when the internal temperature exceeds a safe threshold. Overall, the DeepCool PL550D 550 Watt Non-Modular 80 PLUS Bronze ATX 3.0 Power Supply is an excellent choice for those seeking a dependable and efficient power solution for their computer system.
