Dahua HAC-HFW1200CL-IL-A 2MP Smart Dual Light HDCVI Fixed-focal Bullet Camera

Dahua HAC-HFW1200CL-IL-A 2MP Smart Dual Light HDCVI Fixed-focal Bullet Camera

Model: HAC-HFW1200CL-IL-A

Reviews: No reviews yet

Price: 1,800.00৳

Regular Price: 2,370.00৳

Save: 570.00৳

Key Features:

  • Image Sensor: 2 MP CMOS
  • Max. Resolution: 1920 (H) × 1080 (V)
  • White Balance: Auto; Area white balance
  • Protection: IP67
  • Material: Plastic
  • Warranty Details: 1 Year

Specifications

Camera

Image Sensor 2 MP CMOS
Max. Resolution 1920 (H) × 1080 (V)
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s
Min. Illumination 0.01 lux@F2.0 (Color, 30 IRE)
0.001 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio >65 dB
Illumination Distance IR: 20 m (65.62 ft)
Warm light: 20 m (65.62 ft)
Illuminator On/Off Control Auto
Illuminator Number 2 (Warm light);2 (IR light)
Angle Adjustment Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Lens

Lens Type Fixed-focal
Auto Focus N/A
Lens Mount M12
Focal Length 2.8 mm;3.6 mm
Max. Aperture F2.0
Field of View 2.8 mm: H: 102°; V: 60°; D: 129°
3.6 mm: H: 83°; V: 48°; D: 105°
Iris Control Fixed
Close Focus Distance 2.8 mm: 0.5 m (1.64 ft)
3.6 mm: 0.7 m (2.30 ft)

DORI Distance

Lens 2.8 mm
3.6 mm
Detect 2.8 mm
41.1 m (135.83 ft)
3.6 mm
50.9 m (166.99 ft)
Observe 2.8 mm
16.5 m (42.13 ft)
3.6 mm
20.3 m (66.60 ft)
Recognize 2.8 mm
8.3 m (27.23 ft)
3.6 mm
10.2 m (33.46 ft)
Identify 2.8 mm
4.1 m (13.45 ft)
3.6 mm
5.1 m (16.73 ft)

Video

Video Frame Rate CVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960H;
NTSC: 960H
Resolution 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/Night Auto(ICR)/Color/B/W
BLC BLC; HLC; DWDR
WDR DWDR
White Balance Auto; Area white balance
Gain Control Auto
Noise Reduction 3D NR
Illumination Mode Smart IR&WL; WL Mode; IR Mode
Mirror Yes
Privacy Masking Off/On (8 areas, rectangle)
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Certification

Certifications CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
FCC: 47 CFR FCC Part 15, Subpart B

Audio

Audio Input 1 channel

Power Type

Power Supply 12 VDC ± 30%
Power Consumption Max 2.6W (12 VDC, IR on)

Environmental

Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity <95% (RH), non-condensing
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Storing/Storage Humidity <95% (RH), non-condensing

Protection

Protection IP67

Physical Specification

Material Plastic
Product Dimensions 163.4 mm × 69.7 mm × 70 mm (6.43" × 2.74" × 2.76")
Net Weight 0.18 kg (0.40 lb)
Gross Weight 0.26 kg (0.57 lb)
Installation Wall mount; ceiling mount; vertical pole mount

Warranty Information

Warranty Details 1 Year

Description

Dahua HAC-HFW1200CL-IL-A 2MP Smart Dual Light HDCVI Fixed-focal Bullet Camera

The Dahua HAC-HFW1200CL-IL-A 2MP Smart Dual Light HDCVI Fixed-focal Bullet Camera is a versatile surveillance camera designed for both indoor and outdoor use. It features a 2 MP CMOS image sensor that delivers high-quality video with a maximum resolution of 1920 x 1080. The camera supports H.265+ compression technology, ensuring efficient video storage and transmission. One of the standout features of this camera is its Digital Wide Dynamic Range (DWDR) technology, which enhances image clarity in challenging lighting conditions. Additionally, the camera has EXIR 2.0 advanced infrared technology, which allows for a 20-meter night vision range. The Dahua HAC-HFW1200CL-IL-A offers pan, tilt, and rotation capabilities, with a range of 0 to 360 degrees for pan and rotation, and 0 to 90 degrees for tilt. This allows for flexible adjustment of the camera's field of view to cover different areas. For video output, the camera supports 4 in 1 (CVI/CVBS/AHD/TVI) signals, providing flexibility in connecting to different types of video recorders and monitors. The camera also features a built-in microphone for audio recording, which can be transmitted over the coaxial cable. In terms of installation, the camera has a M12 lens mount and comes with a variety of fixed lenses, including 2.8 mm and 3.6 mm options. The camera's minimum illumination is 0.01 Lux with AGC on, and it can operate in complete darkness with the IR illumination. The Dahua HAC-HFW1200CL-IL-A is designed to be durable and reliable, with a water and dust-resistant (IP67) rating. It operates on a 12 VDC power supply with a maximum power consumption of 2.6 watts. The camera comes with a 1-year warranty for peace of mind. Overall, the Dahua HAC-HFW1200CL-IL-A 2MP Smart Dual Light HDCVI Fixed-focal Bullet Camera is a versatile and high-quality surveillance solution suitable for various indoor and outdoor security needs.

Customer Reviews

No reviews yet. Be the first to leave a review!

Warranty

The Dahua HAC-HFW1200CL-IL-A 2MP Smart Dual Light HDCVI Fixed-focal Bullet Camera comes with a 1-year warranty covering defects in materials and workmanship under normal use.
